UWS
Utility Wrap

naturaLED® Utility Wrap (UWS) now offers the perfect solution for your lighting needs. The Utility Wrap fixtures are designed for saving energy and easy installation. Available in 27W in two color temperatures of 4,000K and 5,000K delivering up to 3,510 lumens with excellent and consistent color. Our Utility Wrap features a full wrap-around UV-coated PC plastic prismatic lens and is 48 inches long; designed for junction box installation and works great in parking garages, stairwells, offices, hallways, industrial, commercial and residential, ceiling or wall mounted. This fixture is versatile and efficient


CategoryUtility Wrap
Wattage27W
Lumens3,510
Voltage120-277V
CCT4000K, 5000K

SPEC SHEET BROCHURE



Description

Item Code
Description
Wattage
CCT
Lumens
Equiv. Watt
Size
Wet/Damp
Motion Sensor
Emergency Driver
Listing
Spec
IES
27W
4000K
3,510
4 x 32W T8
7"x 48"
Damp
P10234
K7336197
27W
5000K
3,510
4 x 32W T8
7"x 48"
Damp
P10234
K7336197

Additional information

Weight 6.88 lbs
Dimensions 48 × 6.90 × 2.58 in
Wattage

CCT

,

CRI

Color

Voltage

Dimmable

Beam Angle

Length

IP Rating

Photocell

Sensor

Listings

,

Warranty

Download

SPEC SHEET INSTALLATION BROCHURE

Accessories

Item Code
Order Code
Description
Data Spec
K7336197
FXUWS-BAEM-MT
Emergency Driver Kit
-
7336
BAEM4-60BC/MV-A
4W CEC-Compliant Emergency
P10249
WG-UWS/48/WH
Wire Guard
-
P10197
PLT-UWS/4FT/WH
Wireway Cover
K234197
FXUWS27-MC605VD-PLT
Motion Sensor with Wireway
Cover Kit
-
P10234
SEN-MC605V-D
Microwave Motion/Photocell
Sensor 120-277V
-
P10407
LENS-UWS27
Replacement Lens
-
P10389
SPD-L-10KV-277
10KV Single Phase Surge Protection
120-277V
P10390
SPD-L-20KV-277
20KV Single Phase Surge Protection
120-277V
P10391
SPD-L-20KV-480
20KV Single Phase Surge Protection
277-480V
