Post Top Area Light Z10 CCT3 PST

PST
Post Top Area Light Z10 Ready CCT3

naturaLED® has designed a sleek, contemporary post top fixture with three vertical arm that creates a clean look. Easy installation to retrofit on standard 2-3/8″ tenons, 3” Pole. Saving time and money by upgrading to LED. Our DLC premium open round post top light fixture replaces up to 250 watt metal halide fixtures and produces up to 12,000 lumens. The preinstalled Z10 Receptacle allows easy plug-and-play control upgrades during installation or at a later time.

Category	Post Top
Wattage	Selectable Wattages
Lumens	3,600~12,000
Voltage	120-277V
CCT	CCT3 (30/40/50K)

SPEC SHEET

Categories: Landscape Lighting, PST

Description

Item Code	Description	Wattage	CCT	Lumens	Equiv. Watt	Color
9728	PST16/60S/T5/8C3/BZ-Z10	30W 45W 60W	3CCT (3000/4000/5000K)	3,600 5,400 7,200	175W	Bronze
9729	PST16/100S/T5/8C3/BZ-Z10	60W 80W 100W	3CCT (3000/4000/5000K)	7,200 9,600 12,000	250W	Bronze
9726	PST16/60S/T5/8C3/BK-Z10	20W 40W 60W	3CCT (3000/4000/5000K)	3,600 5,400 7,200	175W	Black
9727	PST16/100S/T5/8C3/BK-Z10	60W 80W 100W	3CCT (3000/4000/5000K)	7,200 9,600 12,000	250W	Black
9730	PST16/60S/T5/8C3/WH-Z10	20W 40W 60W	3CCT (3000/4000/5000K)	3,600 5,400 7,200	175W	White
9731	PST16/100S/T5/8C3/WH-Z10	60W 80W 100W	3CCT (3000/4000/5000K)	7,200 9,600 12,000	250W	White

Additional information

Weight	13.60 lbs
Dimensions	16 × 16 in
Wattage	Selectable Wattages, 1-50W, 50-100W
CCT	3CCT
CRI	80
Color	Bronze, Black, White
Voltage	120-277V
Dimmable	0-10V
IP Rating	IP65
Photocell	Z10 Compatible
Sensor	Z10 Compatible
Listings	DLC Premium, ETL Listed
Warranty	5 year

Download

SPEC SHEET INSTALLATION

Accessories

Item Code	Order Code	Description	Data Spec
7334	BAEM15-48BC/MV-A	15W CEC Compliant LED Emergency Driver
7336	7336 BAEM4-60BC/MV-A	4W CEC-Compliant LED Emergency Driver 120-277V for 60SW
P10520	SEN-ANT-5-Z10-PC	Z10 Twist-Lock Photocell 12-24Vdc - White	-
P10521	SEN-ANT-5-Z10	Z10 Twist-Lock Microwave Motion	-
P10522	SEN-ANT-6-Z10	Z10 Twist-Lock PIR Motion and Photocell Sensor, 0-10V, 12-24Vdc - White	-
P10316	SEN-BRI-RC100	Remote Programmer	-
