CWX
Compact Full Cut-off Wall Pack

naturaLED® CWX compact cutoff wallpack comes in rugged cast-aluminum housing with excellent thermal design. DLC Premium qualified, our CWX product offers a slim & compact appearance for your wall luminaires.The slim shape maintains an aesthetic appearance to replace any building’s wallpack or perimeter lighting. Ideal for outdoor applications such as carports, loading areas, driveways, parking area and pathways. Designed for wall mounting above four feet from ground. New availabe in Wattage Selectable and Color Temperature Selectable.


CategoryWall Lights
WattageSelectable Wattages
Lumens2,600~5,200
Voltage120-277V
CCTCCT3 (30/40/50K)

SPEC SHEET BROCHURE



Categories: , ,

Description

Item Code
Description
Wattage
CCT
Lumens
Equiv. Watt
Color
Photocell
Listing
Spec
IES
15W
28W
40W
3CCT
(3000/4000/5000K)
2,600
3,640
5,200
175-250W
Bronze
15W
28W
40W
3CCT
(3000/4000/5000K)
2,600
3,640
5,200
175-250W
Black
15W
28W
40W
3CCT
(3000/4000/5000K)
2,600
3,640
5,200
175-250W
White

Additional information

Wattage

,

CCT

Color

, ,

Voltage

Dimmable

IP Rating

Photocell

Sensor

Warranty

Listings

,

Download

SPEC SHEET INSTALLATION Install Sensor & EM BROCHURE

Accessories

Item Code
Order Code
Description
Data Spec
7336
BAEM4-60BC/MV-A
4W CEC Compliant LED Emergency Driver for 60-Watt
P10540
SEN-ANT-11WH
Remote Programmable Microwave Motion Sensor 0-10V Bi-Level Internal 12V Low Voltage
P10518
REC-Z10-WH
Z10 Receptacle Base with the White Cap
P10519
REC-Z10-BK
Z10 Receptacle Base with the Black Cap
P10521
SEN-ANT-5-Z10
Z10 Twist-Lock Microwave Motion & Photocell Sensor, 0-10V,12-24Vdc White
P10522
SEN-ANT-6-Z10
Z10 Twist-Lock PIR Motion & Photocell Sensor, 0-10V,12-24Vdc White
P10316
SEN-BRI-RC100
Remote Programmer for P10540
