VTL
Vapor Tight Linear

naturaLED® linear vapor tight 4-inch is housed in polycarbonate silicon perimeter gasket with brackets for mounting. Engineered for powerful lighting, the IP66-rated LED Vapor Tight Linear Fixtures are designed to replace fluorescent strip fixtures and can be used in parking garage, corporate campu s, education facility, storage facility, car washes, tunnels and stairwell lighting. Using up to 65% less energy and operating for up to 50,000 average life hours, our fixtures comes with selectable wattages and selectable color temperatures.


Category4" Vapor Tight Linear
WattageSelectable Wattages
Lumens2,175~13,050
Voltage120-277V
CCTCCT3 (35/40/50K)

SPEC SHEET BROCHURE

Description

Item Code
Description
Wattage
CCT
Lumens
Equiv. Watt
Size
IP Ratings
Motion Sensor
Emergency Driver
Listing
Spec
IES
15W
20W
25W
3CCT
(35/40/50K)
2,175
2,900
3,625
2 x 32W T8
4"x24"
IP65
P10590
7336
30W
40W
50W
3CCT
(35/40/50K)
4,350
5,800
7,250
2 x 32W T8
4"x48"
IP65
P10590
7336
70W
80W
90W
3CCT
(35/40/50K)
10,150
11,600
13,050
6 x 32W T8
4"x96"
IP65
P10590
7334
30W
40W
50W
3CCT
(35/40/50K)
3,600
4,800
6,000
2 x 32W T8
4"x48"
IP65
P10590
7336

Additional information

Wattage

, ,

CCT

CRI

Color

,

Voltage

Dimmable

Beam Angle

Length

, ,

IP Rating

Photocell

Sensor

Listings

, ,

Warranty

Download

SPEC SHEET INSTALLATION BROCHURE

Accessories

Item Code
Order Code
Description
Data Spec
7336
BAEM4-60BC/MV-A
Emergency Backup Battery with Bracket Kit
For 120-277V only. Fits for 30SW model only #9561
-
7334
BAEM15-48BC/MV-A
Emergency Backup Battery with Bracket Kit
For 120-277V only. Fits for 60SW and 100SW model only
-
P10590
SEN-HD027VCR
45°/90° Angle Mount Bracket for 9561 and 9562
-
P10323
SEN-HD05R
Remote Programmer for K438380 and P10438
-
P10389
SPD-L-10KV-277
10KV Surge Protection 120-277V
P10390
SPD-L-20KV-277
20KV Surge Protection 120-277V
P10391
SPD-L-20KV-480
20KV Surge Protection 347-480V
