• DLC Premium
• IP65 Rated
• ETL/cETL Listed
• Wattage & Color Selectable
• Z10 Remote Ready
• Wattage: 90-150W
• Color Temp: CCT3 (30/40/50K)
• Voltage: 120-277V
• Surge Protection: 20KV
• Dimmable: 0-10V
• CRI >80
• Operating temperature: – 40°F – 122°F
• Beam: Distribution :Type 3 (Optional purchase available for Type 4, Type 5 Lens)
• Material: Die Cast Aluminum
• Finish: Epoxy Powder Coat
• Color: Black
• 7 Year Warranty
| Weight | 8.00 lbs |
|---|---|
| Dimensions | 14.2 × 12.01 × 2.60 in |
| Wattage | |
| CCT | |
| CRI | |
| Voltage | |
| Color | |
| Dimmable | |
| IP Rating | |
| Photocell | |
| Sensor | |
| Listings | |
| Warranty | |
| Stock |
Weight:8.0-lbs
Image | Item Code | Order Code | Description | Data Spec |
|---|---|---|---|---|
 | P10520 | P10520 SEN-ANT-5-Z10-PC | Z10 Twist-Lock Photocell 12-24Vdc - White | - |
 | P10522 | SEN-ANT-6-Z10 | Z10 Twist-Lock PIR Motion and Photocell Sensor, 0-10V, 12-24Vdc - White | - |
 | P10316 | P10316 SEN-BRI-RC100 | Remote Programmer | - |
P10658 | MT-AL/PMA8/90/BZ | Mount - Area Light Pole Mount 90deg Adjustable 8" Bronze | - |
|
P10660 | MT-AL/PMA8/90/BK | Mount - Area Light Pole Mount 90deg Adjustable 8" Black | - |
|
P10659 | MT-AL/PMA8/90/WH | Mount - Area Light Pole Mount 90deg Adjustable 8" White | - |
|
 | P10523 | MT-AL/PMA8/BZ | Mount - Area Light Adjustable Pole Mount 8" Bronze |  |
 | P10525 | MT-AL/PMA8/BK | Mount - Area Light Adjustable Pole Mount 8" Black | |
 | P10524 | MT-AL/PMA8/WH | Mount - Area Light Adjustable Pole Mount 8" White | |
 | P10453 | MT-AL/PM6/BZ | Mount - Area Light Pole Mount 6" Bronze | |
 | P10458 | MT-AL/PM6/WH | Mount - Area Light Pole Mount 6" White | |
 | P10468 | MT-AL/PM6/BK | Mount - Area Light Pole Mount 6" Black | |
 | P10455 | MT-AL/SF/BZ | Mount - Area Light Slip Fitter Bronze | |
 | P10460 | MT-AL/SF/WH | Mount - Area Light Slip Fitter White | |
 | P10470 | MT-AL/SF/BK | Mount - Area Light Slip Fitter Black | |
 | P10473 | MT-AL/WM/BZ | Mount - Slim Area Light Wall Mount Bronze | |
 | P10474 | MT-AL/WM/WH | Mount - Slim Area Light Wall Mount White | |
 | P10475 | MT-AL/WM/BK | Mount - Slim Area Light Wall Mount Black | |
 | P10456 | MT-SAL/YK12/BZ | Mount - SAL Yoke Mount 12" Bronze | |
 | P10461 | MT-SAL/YK12/WH | Mount - SAL Yoke Mount 12" White | |
 | P10471 | MT-SAL/YK12/BK | Mount - SAL Yoke Mount 12" Black | |
 | P10481 | GSFB-SAL/BZ | Glare Shield - SAL Bronze 75W-150W (240W-320W requires 2 per fixture) | - |
 | P10482 | GSFB-SAL/WH | Glare Shield - SAL White 75W-150W (240W-320W requires 2 per fixture) | - |
| P10483 | GSFB-SAL/BK | Glare Shield - SAL Black 75W-150W (240W-320W requires 2 per fixture) | - |
 | P10466 | LENS-SAL-T3-G1 | Type 3 Lens for SAL 25W-150W requires 2 per fixture (240W-320W requires 4 per fixture) | - |
| P10467 | LENS-SAL-T4-G1 | Type 4 Lens for SAL 75W-150W requires 2 per fixture (240W-320W requires 4 per fixture) | - |
| P10499 | LENS-SAL-T5-G1 | Type 5 Lens for SAL 75W-150W requires 2 per fixture (240W-320W requires 4 per fixture) | - |
| P10500 | LENS-SAL-T3-BLC-G1 | Type 3 Back Light Cut Lens for SAL 75W-150W requires 2 per fixture (240W-320W requires 4 per fixture) | - |
 | P10053 | SEN-PHO-LK-MT-SRT | Twist Lock Photocell Shorting Cap 120-480V 3 Prong | - |
 | P10389 | SPD-L-10KV-277 | Surge Protection 10KV 120-277V |  |
| P10390 | SPD-L-20KV-277 | Surge Protection 20KV 120-277V | |
| P10391 | SPD-L-20KV-480 | Surge Protection 20KV 347-480V | |
