| Item Code | 7756 |
|---|---|
| Code | LED-FXTWP28/30K/DB |
| Wattages | 28W |
| Lumens | 3,448 |
| CCT | 3000K |
| Equiv.Wattages | 175W |
| Color | Bronze |
• IP65 Rated
• ETL, cETL Listed
• Wattages: 28W
• Color Temp: 3000K
• Voltage: 120-277V
• Surge Protection: 2KV
• Dimmable: 1-10V
• CRI>70
• Operating Temperature: -22°F – 131°F
• Beam Angle: Forward Throw
• Lens: Borosilicate Glass Lens
• Material: Die Cast Aluminum
• Finish: Corrosion-resistant powder coating
• Color: Bronze
• Warranty: 5 Year
• Optional for Purchase: Photocell Sensor, Microwave Sensor, LED Emergency Drivers Compatible
| Weight | 5.51 lbs |
|---|---|
| Dimensions | 9 × 8.66 × 7.25 in |
| Wattage | |
| CCT | |
| CRI | |
| Voltage | |
| Color | |
| Dimmable | |
| IP Rating | |
| Photocell | |
| Sensor | |
| Listings | |
| Warranty | |
| Stock |
Weight:5.51-lbs
Image | Item Code | Order Code | Description | Data Spec |
|---|---|---|---|---|
  | P10234 | SEN-MC605V-D | Microwave Motion Photocell Sensor 0-10V | - |
 | P10004 | WG-TWP-MEDIUM | Wireguard for Medium TWP 39-60W Size: 14.30”x9.20” |  |
 | 7336 | BAEM4-60BC/MV-A | 4W CEC Compliant LED Emergency Driver for #7756 | |
 | 7334 | BAEM15-48BC/MV-A | 15W CEC Compliant LED Emergency Driver | |
 | P10036 | SEN-PHO-BT-MT/MV | Button Photocell 120-277V | - |
 | P10002 | LENS-TWP-SMALL | Glass Lens Gasket for 28W Size: 9.05”x9.20” | - |
| P10000 | LENS-TWP-MEDIUM | Glass Lens Gasket Size: 14.30”x9.20” | - |
| P10001 | LENS-TWP-LARGE | Glass Lens Gasket Size: 18.5”x9” | - |
| P10003 | LENS-TWP-PC-MEDIUM | Plastic Lens Gasket Size: 14.30”x9.20” | - |
 | P10022 | CVR-TWP-MEDIUM/DB | Full Cut-off Shield for medium Size: 14.5”x9” | |
| P10023 | CVR-TWP-LARGE/DB | Full Cut-off Shield for Size: 18.5”x9” | |
