| Item Code | 7638 |
|---|---|
| Code | LED-FXSAL240/40K/WH/3S |
| Wattages | 240W |
| Lumens | 28,828 |
| CCT | 4000K |
| Equiv.Wattages | 750-1000W |
| Color | White |
• DLC Premium
• IP65 Rated
• ETL/cETL Listed
• Single Wattage & Color Temperature
• Wattage: 240W
• Color Temp: 4000K
• Voltage: 120-277V
• Surge Protection: 12KV
• Dimmable: 1-10V
• CRI >80
• Operating temperature: – 40°F – 122°F
• Beam: Distribution: Type 3 (Optional purchase available for Type 4, Type 5 Lens)
• Material: Die Cast Aluminum
• Finish: Epoxy Powder Coat
• Color: White
• 5 Year Warranty
| Weight | 24.50 lbs |
|---|---|
| Dimensions | 14.96 × 21.57 × 3 in |
| Wattage | |
| CCT | |
| CRI | |
| Voltage | |
| Color | |
| Dimmable | |
| IP Rating | |
| Photocell | |
| Sensor | |
| Listings | |
| Warranty | |
| Stock |
Weight:24.50-lbs
Image | Item Code | Order Code | Description | Data Spec |
|---|---|---|---|---|
P10101 | MT-SAL/SF/DB | Slip Fitter Mount for Slim Area Light - Bronze |  |
|
P10209 | MT-SAL/SF/BK | Slip Fitter Mount for Slim Area Light - Black | ||
P10102 | MT-SAL/SF/WH | Slip Fitter Mount for Slim Area Light - White | |
|
P10103 | MT-SAL/SB/DB | Swivel Bracket Mount for Slim Area Light - Bronze | |
|
P10210 | MT-SAL/SB/BK | Swivel Bracket Mount for Slim Area Light - Black | ||
P10104 | MT-SAL/SB/WH | Swivel Bracket Mount for Slim Area Light - White | |
|
P10105 | MT-SAL/EA6/DB | 6" Inch Extruded Arm for Slim Area Light - Bronze | |
|
P10211 | MT-SAL/EA6/BK | 6" Inch Extruded Arm for Slim Area Light - Black | ||
P10106 | MT-SAL/EA6/WH | 6" Inch Extruded Arm for Slim Area Light - White | ||
P10107 | MT-SAL/DPB/DB | Dual Pendant Box 3/4" NPT - Bronze | |
|
P10108 | MT-SAL/DPB/WH | Dual Pendant Box 3/4" NPT - White | |
|
P10198 | MT-SAL/WM/DB | Wall Mount Small Slim Area Light - Bronze | |
|
P10199 | MT-SAL/WM/WH | Wall Mount Small Slim Area Light - White | |
|
P10111 | MT-SAL/YK9/DB | 9" Yoke Mount for Slim Area Light (29-100W) - Bronze | |
|
P10113 | MT-SAL/YK15/DB | 15" Yoke Mount for Slim Area Light (150-360W) - Bronze | |
|
P10112 | MT-SAL/YK9/WH | 9" Yoke Mount for Slim Area Light (29-100W) - White | |
|
P10114 | MT-SAL/YK15/WH | 15" Yoke Mount for Slim Area Light (150-360W) - White | |
|
P10205 | GSB-SAL-S/DB | Back Glare Shields for Slim Area Light - Bronze (Small - 29 - 100W) | |
|
P10206 | GSB-SAL-S/WH | Back Glare Shields for Slim Area Light - White (Small - 29 - 100W) | |
|
P10207 | GSB-SAL-L/DB | Back Glare Shields for Slim Area Light - Bronze (Large - 150 - 360W) | |
|
P10208 | GSB-SAL-L/WH | Back Glare Shields for Slim Area Light - White (Large - 150 - 360W) | |
|
P10213 | GSF-SAL-S/DB | Front Glare Shields for Slim Area Light - Bronze (Small - 29 - 100W) | |
|
P10214 | GSF-SAL-S/WH | Front Glare Shields for Slim Area Light - White (Small - 29 - 100W) | |
|
P10215 | GSF-SAL-L/DB | Front Glare Shields for Slim Area Light - Bronze (Large - 150 - 360W) | |
|
P10216 | GSF-SAL-L/WH | Front Glare Shields for Slim Area Light - White (Large - 150 - 360W) | |
|
P10119 | MT-SAL/4PA/DB | 4" Round pole adaptor for Slim Area Light - Bronze | |
|
P10120 | MT-SAL/5PA/DB | 5" Round pole adaptor for Slim Area Light - Bronze | |
|
P10121 | MT-SAL/6PA/DB | 6" Round pole adaptor for Slim Area Light - Bronze | |
|
P10122 | MT-SAL/4PA/WH | 4" Round pole adaptor for Slim Area Light - White | |
|
P10123 | MT-SAL/5PA/WH | 5" Round pole adaptor for Slim Area Light - White | |
|
P10124 | MT-SAL/6PA/WH | 6" Round pole adaptor for Slim Area Light - White | |
|
K134115 | PLT/SDB/SWC | PIR Motion/Photocell 0-10V 100-277V 3X C Lens (29-100W) - Bronze Plate | ||
K135115 | PLT/SWH/SWC | PIR Motion/Photocell 0-10V 100-277V 3X C Lens (29-100W) - White Plate | ||
K136115 | PLT/LDB/SWC | PIR Motion/Photocell 0-10V 100-277V 3X C Lens (150-360W) - Bronze Plate | ||
K137115 | PLT/LWH/SWC | PIR Motion/Photocell 0-10V 100-277V 3X C Lens (150-360W) - White Plate | ||
K238X2 | LENS-SAL180-IV | Type 4 Lens for Slim Area Light 150W and 180W | ||
K238X3 | LENS-SAL240-IV | Type 4 Lens for Slim Area Light 240W | ||
K237X4 | LENS-SAL360-IV | Type 4 Lens for Slim Area Light 360W | ||
P10127 | LENS-SAL-SMALL-V | Type 5 Lens for Slim Area Light (29W-100W) | ||
P10131 | LENS-SAL-LARGE-V/WH | Type 5 Lens for Slim Area Light (150W-360W) - White | ||
P10184 | BALED-ESD-240S660DT | 277-480V Driver for SAL 240W |
